• Designed for high-temperature service in 316H applications
• Weld metal composition: 18.8% Cr, 11.5% Ni, 2.35% Mo
• Mechanical strength: 580 N/mm² tensile, 38% elongation, 60 J impact
• Excellent creep strength and thermal stability
• Easy slag removal, soft arc, and finely rippled bead
• Suitable for both flat and positional welding

• Power generation (boilers, superheaters, reheaters)
• Petrochemical and refinery piping
• Fertilizer and chemical plants
• High-pressure steam and utility pipelines
• Thermal process equipment and exchangers

• Shielded Metal Arc Welding (SMAW / MMA)
• Polarity: AC or DC
• Current range:
  • 2.50 mm: 50–80 A
  • 3.15 mm: 70–110 A
  • 3.20 mm: 70–110 A
  • 4.00 mm: 100–150 A
  • 5.00 mm: 140–190 A
• Welding positions: 1G/PA, 2F/PB, 2G/PC, 3G/PF, 4G/PE

Interpass temperature: < 200°C

• Re-dry at 300–350°C for 1–2 hours if required
• Use for components exposed to prolonged high-temperature operation
• Suitable for pressure-bearing joints and critical load-bearing welds
• Provides stable performance in thermally cycled applications
