AWS A5.1: E6013 | DIN EN ISO 2560-A: E 38 0 R 12 | IS 814: ER 4221X
Radiographic Weld Quality, Smooth Bead Appearance, Site Current Tolerance
Rutile medium-coated electrode for structural and pipe welding where precise fit-up and site variability are common. Delivers a forceful yet soft arc, finely rippled weld appearance, and consistent usability across variable current conditions. Optimised for radiographic-quality welds in shipbuilding and construction.
Typical Weld Metal Chemical Composition (%)
| C | Si | Mn | P | S |
| 0.07 | 0.30 | 0.40 | 0.030 | 0.030 |
Typical Mechanical Properties (All Weld Metal)
| Heat Treatment | Tensile Strength
Rm (N/mm2) |
Yield Strength
Rp (N/mm2) |
Elongation
A5 (%) |
Charpy Impact Value
(ISO-V J 0°C) |
| As Welded | 470-540 | ≥ 380 | ≥ 24 | ≥ 60 |
Recommended Welding Parameters
| Diameter (mm) | Amperage Range (A) |
| 2.50 | 60-90 |
| 3.15 | 90-130 |
| 3.20 | 90-130 |
| 4.00 | 140-180 |
| 5.00 | 180-230 |
