StarBlaze Prime 8018 C2
AWS A5.5: E8018-C2 | ISO 2560-A: E 46 6 3Ni B 32 H5
Crack-Resistant Joints | Cold Climate Certified | Nickel-Rich All-Position SMAW
STARBLAZE PRIME 8018 C2 is a high-performance low-hydrogen electrode designed for welding 3.5% Ni steels in extreme cold environments. Engineered for structural and pressure-grade applications down to –100 °C, it produces clean, tough welds with minimal spatter, smooth bead contour, and excellent post-weld mechanical strength—both as-welded and post-heat-treated.
Available Packs
- Dimensions: 2.50 mm x 350 mm, 3.15 mm x 450 mm, 3.20 mm x 450 mm, 4.00 mm x 450 mm, 5.00 mm x 450 mm
- Pack Sizes: 2.5 Kg Pouch, 5 Kg Box
- Master Box: 20 Kg, Customisable packaging available on request
Key Features
- Maintains impact toughness down to –100 °C
- Designed for 3.5% Ni steels in pressure-rated applications
- Excellent crack resistance and X-ray quality welds
- Smooth arc, low spatter, easy slag detachment
- Suitable for both as-welded and PWHT conditions
- Maintains ductility and elongation under thermal shock
Industries
- Cryogenic Tank and Pipe Fabrication
- Heat Exchangers & Pressure Vessel Construction
- Petrochemical & LNG Infrastructure
- Low-Temperature Refinery Systems
- Subzero Storage & Offshore Processing
Processes
- Manual Metal Arc Welding (MMA / SMAW)
- Compatible with AC and DC+ polarity
- Welding positions: PA, PB, PC, PF, PE (All-position qualified)
- Supports PWHT at 620 °C for enhanced ductility and impact
Additional Details
- Recommended base metals include: A352LC3, ASTM A203/A203M Gr. B/D/E, A300D, A333 Gr.3, A334 Gr.3
- Re-dry electrodes at 300–350 °C for 1–2 hours before use
- Store electrodes sealed and dry to retain low-hydrogen characteristics
- Reliable for structural and pressure-rated components in temperature-cycled environments
- Provides >70 J impact strength after PWHT and elongation ≥25%
Product Details
Typical Weld Metal Chemical Composition (%)
| C | Si | Mn | P | S | Ni |
| 0.06 | 0.35 | 0.95 | 0.02 | 0.015 | 3.40 |
Typical Mechanical Properties (All Weld Metal)
| Heat Treatment | Yield Strength Rp (N/mm2) | Tensile Strength Rm (N/mm2) | Elongation A5 (%) | Charpy Impact Value (ISO-V(J) -75°C) |
| As Welded | ≥ 500 | ≥ 580 | ≥ 24 | ≥ 50 |
| PWHT 620°C x 1hr. | ≥ 500 | ≥ 580 | ≥ 25 | ≥ 70 |
Recommended Welding Parameters
| Diameter (mm) | Amperage Range (A) |
| 2.50 | 50-90 |
| 3.15 | 90-130 |
| 3.20 | 90-130 |
| 4.00 | 140-180 |
| 5.00 | 180-230 |
