StarBlaze SS 308L
AWS A5.4: E308L-16 | DIN 8556: E19 9 LR 23 | DIN EN 1600: E19 9 L R 32
Low Carbon. Crack-Resistant. Versatile.
A rutile-basic coated stainless steel electrode, E308L-16 is designed for welding austenitic 18/8 Cr-Ni stainless steels. With a low carbon core wire (308LER) and optimized ferrite (~8%), it offers maximum crack resistance, smooth arc characteristics, and superior corrosion resistance. The electrode produces soft fusion with minimal spatter, excellent slag detachability, and aesthetically clean weld beads. Suitable for use at service temperatures from -120°C to +350°C.
Low carbon content for resistance to intergranular corrosion
Ferrite content (~8%) ensures crack resistance
Excellent bead appearance and easy slag removal
Very low moisture pick-up and easy re-strike
Soft fusion characteristics with minimal spatter
Suitable for both AC and DC+ polarity
Food & Beverage Processing
Pharmaceutical Equipment
Petrochemical & Chemical Plants
Shipbuilding & Marine Fabrication
Heat Exchanger & Pressure Vessel Manufacturing
Pulp & Paper Industry
Architectural Stainless Structures
Manual Metal Arc Welding (MMA/SMAW)
Positional welding (horizontal, vertical up/down, overhead)
Stainless steel fabrication and assembly
Maintenance and repair of austenitic stainless steel components
Structural welds on 18/8 stainless steel grades (304, 304L, 308, 308L, 321, 347)
Product Details
Typical Mechanical Properties (All Weld Metal)
| Tensile Strength (Rm) | Elongation | Impact Strength (ISO-V @ RT) |
|---|---|---|
| 610 N/mm² | 44% | 60 Joules |
Recommended Welding Parameters
| Diameter (mm) | Amperage Range (A) |
|---|---|
| 2.50 | 50 – 80 |
| 3.15 | 80 – 110 |
| 4.00 | 110 – 150 |
| 5.00 | 150 – 180 |
