AWS A5.4: E308L-16 | DIN EN ISO 3581-A: E 19 9 LR 12 | DIN EN 1600: E 19 9 LR 12 | Werkstoff Nr: 1.4316
Extra Low Carbon, 800°C Scaling Resistance, Smooth Arc and Finish
Extra low carbon rutile-basic stainless electrode with ~8% ferrite for corrosion and crack resistance in 18/8 stainless steels. Offers soft arc behaviour with minimal spatter, clean slag release, and excellent bead quality. Effective in operating temperatures from –120°C to +350°C with scaling resistance up to 800°C.
Available Packs
Dimensions: 2.50 mm x 350 mm, 3.15 mm x 450 mm, 4.00 mm x 450 mm
Pack Sizes: 2.5 Kg Pouch, 5 Kg Box
Master Box: 20 Kg, 30 Kg, 40 Kg, Customisable packaging available on request
Typical Weld Metal Chemical Composition (%)
| C | Mn | Si | Cr | Ni | P | S |
| 0.02 | 0.90 | 0.80 | 19.0 | 10.0 | 0.015 | 0.010 |
Typical Mechanical Properties (All Weld Metal)
| Tensile Strength
Rm (N/mm2) |
Elongation
A5 (%) |
Charpy Impact Value
(ISO-V J RT) |
| 610 | 40 | 70 |
Recommended Welding Parameters
| Diameter (mm) | Amperage Range (A) |
| 2.50 | 50-80 |
| 3.15 | 70-110 |
| 3.20 | 70-110 |
| 4.00 | 100-150 |
| 5.00 | 140-190 |
