Description
Typical Chemical Composition (%)
| C | Mn | Si | Cr | Ni | Mo | Cu | S | P | Ti | Nb + Ta | Al | Fe |
| 0.10 max | 0.50 max | 0.50 max | 20.00 – 23.00 | 58.00 min | 8.00 – 10.00 | 0.50 max | 0.015 max | 0.015 max | 0.40 max | 3.15 – 4.15 | 0.40 max | 5.00 max |
Typical All-Weld Mechanical Properties
| Yield Strength (N/mm²) | Tensile Strength (N/mm²) | Elongation A5 (%) | Impact Energy ISO-V(J) 20°C |
| ≥ 350 | ≥ 750 | ≥ 25% | ≥ 100 |
Recommended Welding Data
| Diameter (mm) | 2.00 | 2.40 | 3.20 | 4.00 |
| Current (A) | 190 – 500 | 300 – 500 | 300 – 500 | 300 – 500 |
| Voltage (V) | 24 – 30 | 26 – 30 | 28 – 30 | 28 – 32 |
